EcoTab-15Plus Tablet Press

  • Application
  • Features
  • Technical Data

EcoTab-15Plus Tablet Press

The EcoTab-15Plus rotary tablet press is a versatile machine. It can press a diverse range of granular materials, including various types of tablets (Chinese and Western medicine, calcium, buccal, etc.), food items (milk, candy), and products from industries such as electronics, metallurgy (ceramic grains), and more.

EcoTab-15Plus Tablet Press

  • Function & Application: For pressing round tablets from granules, suitable for batch production.
  • Adjustable Parameters: Adjustable turret rotation speed, filling depth, and tablet thickness during operation.
  • Overload Protection: Mechanical buffer unit to prevent punch and apparatus overload damage.
  • Powder Management: Powder suction unit to collect and reuse residual powder.
Technical DataEcoTab-15Plus
Quantity of Punch & Die (set)15
Max. Pressure (kn)120
Max. Dia. of Tablet (mm)50
Max. Thickness of Tablet (mm)18
Max. Depth of Filling (mm)35
Rotate Speed (r/min)0-20
Production Capacity (pcs/h)38400
Motor Power (kw)7.5
Overall Size (mm)1250×980×1650
Weight (kg)1850
Download Brochure
